Hydraulic hose EN 853 – 2SN – SAE 100 R2AT
| INNER TUBE: | black, oil resistant synthetic rubber |
| REINFORCEMENT: | one high tensile textile braid |
| COVER: | black, weather and ozone resistant synthetic rubber |
| TEMP. OF APPLICATION: | -40° C do +100° C with peaks up to +125° C |
| APPLICATION: | high pressure hydraulic lines, fuel oil, water and air |
| NP6 | NP8 | NP10 | NP13 | NP16 | NP20 | NP25 | NP32 | NP40 | NP50 | |
| Inside diameter (mm) |
6.4 | 7.9 | 9.5 | 12.7 | 15.9 | 19.0 | 25.4 | 31.8 | 38.1 | 50.8 |
| Outside diameter | 14.2 | 15.8 | 18.2 | 21.3 | 24.5 | 28.6 | 36.6 | 46.0 | 52.8 | 65.6 |
| Max. working pressure (bar) |
400 | 350 | 330 | 275 | 250 | 215 | 165 | 125 | 90 | 80 |
| Min. Bending radius (mm) |
100 | 115 | 125 | 175 | 200 | 240 | 300 | 420 | 500 | 630 |
